DIY Mini Split
Systems
Built to Last.
Professional-grade ductless heating and cooling — engineered for self-installation. No vacuum pump. No contractor. No compromise.
Ductless • Flareless line sets — cut to length • Mix King & Emperor indoor handlers
GWIN 22 Multi 18,000 BTU 2 Zone Condenser
- Up to 2 independent zones
- 230V single phase
- Complete system
- All GWIN™ guarantees
GWIN 22 Multi 18k 2 Zone Multi Zone Condenser The GWIN King 22 18k 2 Zone Multi Zone Condenser is a compact and efficient outdoor heat pump designed to power up to 2 indoor zones from a single system. Built for flexib...
GWIN 22 Multi 18k 2 Zone Multi Zone Condenser
The GWIN King 22 18k 2 Zone Multi Zone Condenser is a compact and efficient outdoor heat pump designed to power up to 2 indoor zones from a single system. Built for flexibility and performance, this multi-zone ductless condenser allows independent temperature control in multiple rooms while reducing installation complexity and equipment footprint.
With up to 22 SEER2 efficiency, this system delivers energy-conscious operation while maintaining consistent comfort across zones. It utilizes R32 refrigerant for improved efficiency and reduced environmental impact.
GWIN Tech Included — Installation with Confidence Built in
Unlike traditional systems, this condenser includes GWIN Tech - first of its kind, giving you access to expert assistance during commission start up. This means you’re not commissioning blindly — you have professional-level reviewal available to help ensure your system is configured correctly and running at peak performance.
- Expert commissioning included
- Confidence for Assisted DIY install and professional commission
- Reduces installation errors and callbacks
- Helps ensure optimal system performance from day one
Flexible Multi-Zone Comfort
This system allows you to connect up to two indoor air handlers to a single outdoor unit, making it ideal for homes, additions, or spaces where ductwork is not practical.
Key Features
- 18,000 BTU multi-zone condenser
- Supports up to 2 indoor units
- Up to 22 SEER2 efficiency
- R32 refrigerant
- Independent zone temperature control
- Inverter-driven compressor
- Compact outdoor footprint
- Intelligent defrost
- Self-diagnosis
- Low ambient operation
- Quiet operation
- GWIN Tech included for commissioning and support
Reliable Cold Weather Performance
This system is designed for dependable performance in a wide range of climates, supporting heating operation in low outdoor temperatures.
Ideal Applications
This 2-zone ductless mini-split condenser is ideal for homes, apartments, additions, garages, and offices where multiple rooms require independent comfort control.
System Information
| System Type | Multi-Zone Heat Pump |
| Outdoor Model | GMULTI18HP230V1R32AO |
| Max Zones | 2 Zones |
| Compatible Indoor Units | Wall Mount, Cassette, Ducted, Floor/Ceiling |
| Installation Support | GWIN Tech Included |
Performance Specifications
| Rated Cooling Capacity | 18,000 BTU/h |
| Rated Heating Capacity | 18,000 BTU/h |
| SEER2 | Up to 22 |
*GWIN Tech only covers commissioning of system, not install or incorrectly installed systems.
GWIN 22 Multi 24,000 BTU 3 Zone Condenser
- Up to 3 independent zones
- 230V single phase
- Complete system
- All GWIN™ guarantees
GWIN 22 Multi 24k 3 Zone Multi Zone Condenser The GWIN King 22 24k 3 Zone Multi Zone Condenser is a powerful and efficient outdoor heat pump designed to power up to 3 indoor zones from a single system. Built for flexi...
GWIN 22 Multi 24k 3 Zone Multi Zone Condenser
The GWIN King 22 24k 3 Zone Multi Zone Condenser is a powerful and efficient outdoor heat pump designed to power up to 3 indoor zones from a single system. Built for flexibility and performance, this multi-zone ductless condenser allows independent temperature control in multiple rooms while reducing installation complexity and equipment footprint.
With up to 22 SEER2 efficiency, this system delivers energy-conscious operation while maintaining consistent comfort across zones. It utilizes R32 refrigerant for improved efficiency and reduced environmental impact.
GWIN Tech Included — Installation with Confidence Built in
Unlike traditional systems, this condenser includes GWIN Tech - first of its kind, giving you access to expert assistance during commission start up. This means you’re not commissioning blindly — you have professional-level reviewal available to help ensure your system is configured correctly and running at peak performance.
- Expert commissioning included
- Confidence for Assisted DIY install and professional commission
- Reduces installation errors and callbacks
- Helps ensure optimal system performance from day one
Flexible Multi-Zone Comfort
This system allows you to connect up to three indoor air handlers to a single outdoor unit, making it ideal for homes, additions, or spaces where ductwork is not practical.
Key Features
- 24,000 BTU multi-zone condenser
- Supports up to 3 indoor units
- Up to 22 SEER2 efficiency
- R32 refrigerant
- Independent zone temperature control
- Inverter-driven compressor
- Compact outdoor footprint
- Intelligent defrost
- Self-diagnosis
- Low ambient operation
- Quiet operation
- GWIN Tech included for commissioning and support
Reliable Cold Weather Performance
This system is designed for dependable performance in a wide range of climates, supporting heating operation in low outdoor temperatures.
Ideal Applications
This 3-zone ductless mini-split condenser is ideal for homes, apartments, additions, garages, and offices where multiple rooms require independent comfort control.
System Information
| System Type | Multi-Zone Heat Pump |
| Outdoor Model | GMULTI24HP230V1R32AO |
| Max Zones | 3 Zones |
| Compatible Indoor Units | Wall Mount, Cassette, Ducted, Floor/Ceiling |
| Installation Support | GWIN Tech Included |
Performance Specifications
| Rated Cooling Capacity | 24,000 BTU/h |
| Rated Heating Capacity | 24,000 BTU/h |
| SEER2 | Up to 22 |
*GWIN Tech only covers commissioning of system, not install or incorrectly installed systems.
GWIN 22 Multi 30,000 BTU 4 Zone Condenser
- Up to 4 independent zones
- 230V single phase
- Heating to −22°F
- Complete system
- All GWIN™ guarantees
GWIN 22 Multi 30k 4 Zone Multi Zone Condenser The GWIN King 21 30k 4 Zone Multi Zone Condenser is a powerful and efficient outdoor heat pump designed to power up to 4 indoor zones from a single system. Built for flexi...
GWIN 22 Multi 30k 4 Zone Multi Zone Condenser
The GWIN King 21 30k 4 Zone Multi Zone Condenser is a powerful and efficient outdoor heat pump designed to power up to 4 indoor zones from a single system. Built for flexibility and performance, this multi-zone ductless condenser allows independent temperature control in multiple rooms while reducing installation complexity and equipment footprint.
With up to 21 SEER2 efficiency, this system delivers energy-conscious operation while maintaining consistent comfort across zones. It utilizes R32 refrigerant for improved efficiency and reduced environmental impact.
GWIN Tech Included — Installation with Confidence Built in
Unlike traditional systems, this condenser includes GWIN Tech - first of its kind, giving you access to expert assistance during commission start up. This means you’re not commissioning blindly — you have professional-level reviewal available to help ensure your system is configured correctly and running at peak performance.
- Expert commissioning included
- Confidence for Assisted DIY install and professional commission
- Reduces installation errors and callbacks
- Helps ensure optimal system performance from day one
Flexible Multi-Zone Comfort
This system allows you to connect up to four indoor air handlers to a single outdoor unit, making it ideal for homes, additions, or spaces where ductwork is not practical.
Key Features
- 30,000 BTU multi-zone condenser
- Supports up to 4 indoor units
- Up to 21 SEER2 efficiency
- R32 refrigerant
- Independent zone temperature control
- Inverter-driven compressor
- Low ambient cooling down to -22°F
- Low ambient heating down to -22°F
- Blue Fin coated outdoor coil
- Intelligent defrost
- Self-diagnosis
- Quiet operation
- GWIN Tech included for commissioning and support
Reliable Cold Weather Performance
This system is designed for dependable performance in a wide range of climates, supporting cooling operation from -22°F to 118°F and heating operation from -22°F to 75°F.
Ideal Applications
This 4-zone ductless mini-split condenser is ideal for homes, apartments, additions, garages, and offices where multiple rooms require independent comfort control.
System Information
| System Type | Multi-Zone Heat Pump |
| Outdoor Model | GMULTI30HP230V1R32AO |
| Max Zones | 4 Zones |
| Compatible Indoor Units | Wall Mount, Cassette, Ducted, Floor/Ceiling, One Way Cassette, Mini-Console |
| Installation Support | GWIN Tech Included |
Performance Specifications
| Rated Cooling Capacity | 28,400 BTU/h |
| Rated Heating Capacity | 30,000 BTU/h |
| SEER2 | Up to 21 |
*GWIN Tech only covers commissioning of system, not install or incorrectly installed systems.
GWIN 22 Multi 36,000 BTU 4 Zone Condenser
- Up to 4 independent zones
- 230V single phase
- Complete system
- All GWIN™ guarantees
GWIN 22 Multi 36k 4 Zone Multi Zone Condenser The GWIN King 22 36k 4 Zone Multi Zone Condenser is a compact and efficient outdoor heat pump designed to power up to 4 indoor zones from a single system. Built for flexib...
GWIN 22 Multi 36k 4 Zone Multi Zone Condenser
The GWIN King 22 36k 4 Zone Multi Zone Condenser is a compact and efficient outdoor heat pump designed to power up to 4 indoor zones from a single system. Built for flexibility and performance, this multi-zone ductless condenser allows independent temperature control in multiple rooms while reducing installation complexity and equipment footprint.
With up to 21 SEER2 efficiency, this system delivers energy-conscious operation while maintaining consistent comfort across zones. It utilizes R32 refrigerant for improved efficiency and reduced environmental impact.
GWIN Tech Included — Installation with Confidence Built in
Unlike traditional systems, this condenser includes GWIN Tech - first of its kind, giving you access to expert assistance during commission start up. This means you’re not commissioning blindly — you have professional-level reviewal available to help ensure your system is configured correctly and running at peak performance.
- Expert commissioning included
- Confidence for Assisted DIY install and professional commission
- Reduces installation errors and callbacks
- Helps ensure optimal system performance from day one
Flexible Multi-Zone Comfort
This system allows you to connect up to four indoor air handlers to a single outdoor unit, making it ideal for homes, additions, or spaces where ductwork is not practical.
Key Features
- 36,000 BTU multi-zone condenser
- Supports up to 4 indoor units
- Up to 21 SEER2 efficiency
- R32 refrigerant
- Independent zone temperature control
- Inverter-driven compressor
- Compact outdoor footprint
- Intelligent defrost
- Self-diagnosis
- Low ambient operation
- Quiet operation
- GWIN Tech included for commissioning and support
Reliable Cold Weather Performance
This system is designed for dependable performance in a wide range of climates, supporting heating operation in low outdoor temperatures.
Ideal Applications
This 4-zone ductless mini-split condenser is ideal for homes, apartments, additions, garages, and offices where multiple rooms require independent comfort control.
System Information
| System Type | Multi-Zone Heat Pump |
| Outdoor Model | MUL36HP230V1R32AO |
| Max Zones | 4 Zones |
| Compatible Indoor Units | Wall Mount, Cassette, Ducted, Floor/Ceiling |
| Installation Support | GWIN Tech Included |
Performance Specifications
| Rated Cooling Capacity | 36,000 BTU/h |
| Rated Heating Capacity | 36,000 BTU/h |
| SEER2 | Up to 21 |
*GWIN Tech only covers commissioning of system, not install or incorrectly installed systems.
GWIN 22 Multi 42,000 BTU 5 Zone Condenser
- Up to 5 independent zones
- 230V single phase
- Heating to −22°F
- Complete system
- All GWIN™ guarantees
GWIN 22 Multi 42k 5 Zone Multi Zone Condenser The GWIN King 21 42k 5 Zone Multi Zone Condenser is a high-capacity outdoor heat pump designed to power up to 5 indoor zones from a single system. Built for maximum flexib...
GWIN 22 Multi 42k 5 Zone Multi Zone Condenser
The GWIN King 21 42k 5 Zone Multi Zone Condenser is a high-capacity outdoor heat pump designed to power up to 5 indoor zones from a single system. Built for maximum flexibility and performance, this multi-zone ductless condenser allows independent temperature control across multiple rooms while minimizing installation complexity and outdoor equipment footprint.
With up to 21 SEER2 efficiency, this system delivers strong energy performance while maintaining consistent comfort across all connected zones. It utilizes R32 refrigerant for improved efficiency and reduced environmental impact.
GWIN Tech Included — Installation with Confidence Built in
Unlike traditional systems, this condenser includes GWIN Tech - first of its kind, giving you access to expert assistance during commission start up. This means you’re not commissioning blindly — you have professional-level reviewal available to help ensure your system is configured correctly and running at peak performance.
- Expert commissioning included
- Confidence for Assisted DIY install and professional commission
- Reduces installation errors and callbacks
- Helps ensure optimal system performance from day one
Flexible Multi-Zone Comfort
This system allows you to connect up to five indoor air handlers to a single outdoor unit, making it ideal for whole-home applications, additions, or properties where ductwork is not practical.
Key Features
- 42,000 BTU multi-zone condenser
- Supports up to 5 indoor units
- Up to 21 SEER2 efficiency
- R32 refrigerant
- Independent zone temperature control
- Inverter-driven compressor
- Low ambient cooling down to -22°F
- Low ambient heating down to -22°F
- Blue Fin corrosion protection
- Intelligent defrost
- Self-diagnosis
- Quiet operation
- GWIN Tech included for commissioning and support
Reliable Cold Weather Performance
This system is designed for dependable performance in extreme climates, operating in cooling from -22°F to 118°F and heating from -22°F to 75°F.
Ideal Applications
This 5-zone ductless mini-split condenser is ideal for whole-home applications, large residences, multi-room additions, offices, and properties requiring independent climate control across multiple spaces.
System Information
| System Type | Multi-Zone Heat Pump |
| Outdoor Model | GMULTI42HP230V1R32AO |
| Max Zones | 5 Zones |
| Compatible Indoor Units | Wall Mount, Cassette, Ducted, Floor/Ceiling, One Way Cassette, Mini-Console |
| Installation Support | GWIN Tech Included |
Performance Specifications
| Rated Cooling Capacity | 42,000 BTU/h |
| Rated Heating Capacity | 42,000 BTU/h |
| SEER2 | Up to 21 |
*GWIN Tech only covers commissioning of system, not install or incorrectly installed systems.
GWIN 22 Multi 48,000 BTU 5 Zone Condenser
- Up to 5 independent zones
- 230V single phase
- Heating to −22°F
- Complete system
- All GWIN™ guarantees
GWIN 22 Multi 48k 5 Zone Multi Zone Condenser The GWIN King 22 48k 5 Zone Multi Zone Condenser is a premium, high-capacity outdoor heat pump designed to power up to 5 indoor zones from a single system. Built for maxim...
GWIN 22 Multi 48k 5 Zone Multi Zone Condenser
The GWIN King 22 48k 5 Zone Multi Zone Condenser is a premium, high-capacity outdoor heat pump designed to power up to 5 indoor zones from a single system. Built for maximum flexibility and performance, this multi-zone ductless condenser delivers independent climate control across multiple rooms while minimizing installation complexity and outdoor equipment footprint.
With up to 21 SEER2 efficiency, this system provides strong energy performance while maintaining consistent comfort across all connected zones. It utilizes R32 refrigerant for improved efficiency and reduced environmental impact.
GWIN Tech Included — Installation with Confidence Built in
Unlike traditional systems, this condenser includes GWIN Tech - first of its kind, giving you access to expert assistance during commission start up. This means you’re not commissioning blindly — you have professional-level reviewal available to help ensure your system is configured correctly and running at peak performance.
- Expert commissioning included
- Confidence for Assisted DIY install and professional commission
- Reduces installation errors and callbacks
- Helps ensure optimal system performance from day one
Flexible Whole-Home Comfort
This system allows you to connect up to five indoor air handlers to a single outdoor unit, making it ideal for whole-home applications, multi-room additions, and properties where ductwork is not practical.
Key Features
- 48,000 BTU multi-zone condenser
- Supports up to 5 indoor units
- Up to 21 SEER2 efficiency
- R32 refrigerant
- Independent zone temperature control
- Inverter-driven compressor
- Low ambient cooling down to -22°F
- Low ambient heating down to -22°F
- Blue Fin corrosion protection
- Intelligent defrost
- Self-diagnosis
- Quiet operation
- GWIN Tech included for commissioning and support
Reliable Cold Weather Performance
This system is engineered for dependable performance in extreme climates, operating in cooling from -22°F to 118°F and heating from -22°F to 75°F.
Ideal Applications
This 5-zone ductless mini-split condenser is ideal for large homes, whole-home retrofits, multi-room additions, offices, and properties requiring independent climate control across multiple zones.
System Information
| System Type | Multi-Zone Heat Pump |
| Outdoor Model | GMULTI48HP230V1R32AO |
| Max Zones | 5 Zones |
| Compatible Indoor Units | Wall Mount, Cassette, Ducted, Floor/Ceiling, One Way Cassette, Mini-Console |
| Installation Support | GWIN Tech Included |
Performance Specifications
| Rated Cooling Capacity | 48,000 BTU/h |
| Rated Heating Capacity | 48,000 BTU/h |
| SEER2 | Up to 21 |
*GWIN Tech only covers commissioning of system, not install or incorrectly installed systems.
Flareless 1/4 x 3/8 GWIN Line Set for 7k, 9k, & 12k BTU Ductless Mini Split Air Handlers
Flareless 1/4 x 3/8 GWIN Line Set for 7k, 9k, & 12k BTU Air Handlers **Will not work on the ducted mini splits** **FOR CUSTOMERS DOING A SELF INSTALL** For contractors the Flared line set click this link: FLARED...
Flareless 1/4 x 3/8 GWIN Line Set for 7k, 9k, & 12k BTU Air Handlers
**Will not work on the ducted mini splits**
**FOR CUSTOMERS DOING A SELF INSTALL**
For contractors the Flared line set click this link: FLARED LINE SET
Flareless 1/4 x 1/2 GWIN Line Set for 18k & 20k BTU Ductless Mini Split Air Handlers
Flareless 1/4 x 1/2 GWIN Line Set for 18k BTU Ductless Mini Split Air Handlers **Will not work on the ducted mini splits** **FOR CUSTOMERS DOING A SELF INSTALL** For contractors the Flared line set click this link: F...
Flareless 1/4 x 1/2 GWIN Line Set for 18k BTU Ductless Mini Split Air Handlers
**Will not work on the ducted mini splits**
**FOR CUSTOMERS DOING A SELF INSTALL**
For contractors the Flared line set click this link: FLARED LINE SET
Flareless 1/4 x 5/8 GWIN Line Set for 24k, 30k, & 36k BTU Ductless Mini Split Air Handlers
Flareless 1/4 x 5/8 GWIN Line Set for 24k & 36k BTU Ductless Mini Split Air Handlers **Will not work on the ducted mini splits** **FOR CUSTOMERS DOING A SELF INSTALL** For contractors the Flared line set click th...
Flareless 1/4 x 5/8 GWIN Line Set for 24k & 36k BTU Ductless Mini Split Air Handlers
**Will not work on the ducted mini splits**
**FOR CUSTOMERS DOING A SELF INSTALL**
For contractors the Flared line set click this link: FLARED LINE SET
GWIN 7,000 BTU 230V King Multi-Zone Ductless Wall Mount Air Handler
- 230V single phase
- All GWIN™ guarantees
GWIN 7,000 BTU 230V King Multi-Zone Ductless Wall Mount Air Handler The GWIN 7,000 BTU 230V King Multi-Zone Ductless Wall Mount Air Handler is an indoor wall-mounted unit designed for multi-zone heat pump applications...
GWIN 7,000 BTU 230V King Multi-Zone Ductless Wall Mount Air Handler
The GWIN 7,000 BTU 230V King Multi-Zone Ductless Wall Mount Air Handler is an indoor wall-mounted unit designed for multi-zone heat pump applications. It delivers 7,000 BTU/h nominal cooling and 8,000 BTU/h nominal heating and is powered by the connected outdoor unit.
This unit is built for quiet, efficient indoor comfort and includes WiFi, a wired controller interface, a crossflow fan, and multiple fan speed options for flexible day-to-day operation. System performance values such as SEER2, EER2, HSPF2, COP, and temperature range depend on the connected outdoor unit.
Comfort & Control
This indoor air handler includes a full range of remote controller functions for customizable operation and everyday convenience.
- Auto Mode
- Auto Fan
- Horizontal Auto Swing
- Vertical Auto Swing
- Clock on Remote Controller
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- I Feel Function
- Lock on Remote Controller
- Quiet Mode
- Room Temperature Display
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode (46°F)
Key Features
- 7,000 BTU/h nominal cooling capacity
- 8,000 BTU/h nominal heating capacity
- 208-230V / 1Ph / 60Hz power supply
- Powered by the outdoor unit
- WiFi included
- Wired controller interface
- Crossflow indoor fan
- 7 fan speeds
- Indoor unit display
- R32 refrigerant
Installation & Compatibility
This wall-mounted indoor unit is designed for use in a multi-zone heat pump system and uses 1/4" - 3/8" flared refrigerant line connections. Electrical power is supplied through the connected outdoor unit.
Technical Specifications
| System Type | Heat Pump |
| Indoor Model | KING07HP230V1R32AH |
| Cooling Capacity | 7,000 BTU/h (Nominal) |
| Heating Capacity | 8,000 BTU/h (Nominal) |
| Refrigerant Type | R32 |
| Power Supply | 208-230V / 1Ph / 60Hz (Powered by the Outdoor Unit) |
| Air Flow (Min - Max) | 135 - 259 CFM |
| Sound Pressure Level (Min - Max) | 23 - 38 dB(A) |
| Dehumidification | 1.27 pt/hr |
| External Dimensions (W x H x D) | 27-7/8 x 10-15/64 x 7-18/64 in. |
| Package Dimensions (W x H x D) | 29-41/64 x 13-5/64 x 10-10/64 in. |
| Net Weight | 15.4 lbs |
| Gross Weight | 18.7 lbs |
| Line Set Size (Liquid - Gas) | 1/4" - 3/8" |
| Wired Controller Interface | Yes |
| WiFi Included | Yes |
| Indoor Fan Type | Crossflow |
| Multi Fan Speeds | 7 Speeds |
| Indoor Unit Display | Yes |
| Auxiliary Electrical Heater | No |
| Ventilation (Outdoor Air) | No |
| Performance Note | System performance is based on the connected outdoor unit performance. |
GWIN 9,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler
- 230V single phase
- All GWIN™ guarantees
GWIN 9,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler The GWIN 9,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit design...
GWIN 9,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler
The GWIN 9,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit designed to deliver targeted comfort with quiet operation and modern control features. Ideal for bedrooms, offices, and small living spaces, this wall-mounted air handler provides precise temperature control while maintaining energy efficiency.
Built with advanced inverter technology and optimized airflow design, this unit ensures consistent comfort while minimizing energy consumption. Its compact design allows for flexible installation without compromising performance.
Comfort & Control
This indoor unit includes an intuitive remote control system, allowing users to easily adjust temperature, fan speed, and operating modes for personalized comfort.
- Wireless remote control included
- Auto Mode
- Auto Fan
- Horizontal Auto Swing
- Vertical Auto Swing
- Clock on Remote Controller
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- I Feel Function
- Lock on Remote Controller
- Quiet Mode
- Room Temperature Display
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode (46°F)
Key Features
- 9,000 BTU cooling and heating capacity
- 208-230V power supply
- Wall-mounted compact design
- Inverter-driven performance
- Whisper-quiet operation
- Energy-efficient operation
Installation & Compatibility
This indoor air handler is designed to pair seamlessly with the GWIN King Single Zone condenser for a complete ductless system solution.
Technical Specifications
| Model Number | KING09HP230V1R32AH |
| Cooling Capacity | 9,000 BTU/h |
| Heating Capacity | 10,000 BTU/h |
| Power Supply | 208-230V / 1Ph / 60Hz (Powered by the Outdoor Unit) |
| Electrical Connection | Indoor to Outdoor Communication Wiring Required |
| Voltage Range (Min - Max) | 187 - 253 VAC |
| Rated Current - Cooling | 4.8 A |
| Rated Current - Heating | 4.4 A |
| MOCP | 15 A |
| MCA | 7 A |
| Main Power Wire Size | Per Local Code |
| Interconnecting Wire Size | 14 / 4 AWG |
| Line Set Size (Liquid - Gas) | 1/4" - 3/8" |
| Pipe Length (Min - Max) | 10 - 82 ft. |
| Max Pipe Elevation | 49 ft. |
| Dehumidification | 2.11 pt/hr |
| Air Flow (Min-Max) | 235 - 424 CFM |
| Sound Pressure Level | 27 - 45 dB(A) |
| External Dimensions (W x H x D) | 32-7/8 x 10-53/64 x 7-7/8 in. |
| Package Dimension (W x H x D) | 35-15/64 x 13-37/64 x 10-43/64 in. |
| Net Weight | 19.8 lbs. |
| Gross Weight | 24.3 lbs. |
GWIN 09,000 BTU 230V Emperor Single Ductless Wall Mount Air Handler
- 230V single phase
- All GWIN™ guarantees
GWIN 9,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler The GWIN 09,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit designed to...
GWIN 9,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler
The GWIN 09,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit designed to deliver targeted comfort with quiet operation and modern control features. Ideal for bedrooms, offices, and small living spaces, this wall-mounted air handler provides precise temperature control while maintaining energy efficiency.
Built with advanced inverter technology and optimized airflow design, this unit ensures consistent comfort while minimizing energy consumption. Its compact design allows for flexible installation without compromising performance.
Comfort & Control
This indoor unit includes an intuitive remote control system, allowing users to easily adjust temperature, fan speed, and operating modes for personalized comfort.
- Wireless remote control included
- Auto Mode
- Auto Fan
- Horizontal Auto Swing
- Vertical Auto Swing
- Clock on Remote Controller
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- I Feel Function
- Lock on Remote Controller
- Quiet Mode
- Room Temperature Display
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode (46°F)
Key Features
- 9,000 BTU cooling and heating capacity
- 208-230V power supply
- Wall-mounted compact design
- Inverter-driven performance
- Whisper-quiet operation
- Energy-efficient operation
Installation & Compatibility
This indoor air handler is designed to pair seamlessly with the GWIN King Single Zone condenser for a complete ductless system solution.
Technical Specifications
| Model Number | EMPR09HP230V1R32AH |
| Cooling Capacity | 9,000 BTU/h |
| Heating Capacity | 10,000 BTU/h |
| Power Supply | 208-230V / 1Ph / 60Hz (Powered by the Outdoor Unit) |
| Electrical Connection | Indoor to Outdoor Communication Wiring Required |
| Voltage Range (Min - Max) | 187 - 253 VAC |
| Rated Current - Cooling | 4.8 A |
| Rated Current - Heating | 4.4 A |
| MOCP | 15 A |
| MCA | 7 A |
| Main Power Wire Size | Per Local Code |
| Interconnecting Wire Size | 14 / 4 AWG |
| Line Set Size (Liquid - Gas) | 1/4" - 3/8" |
| Pipe Length (Min - Max) | 10 - 82 ft. |
| Max Pipe Elevation | 49 ft. |
| Dehumidification | 2.11 pt/hr |
| Air Flow (Min-Max) | 235 - 424 CFM |
| Sound Pressure Level | 27 - 45 dB(A) |
| External Dimensions (W x H x D) | 32-7/8 x 10-53/64 x 7-7/8 in. |
| Package Dimension (W x H x D) | 35-15/64 x 13-37/64 x 10-43/64 in. |
| Net Weight | 19.8 lbs. |
| Gross Weight | 24.3 lbs. |
GWIN 9,000 BTU 230V Emperor and Multi-Zone Slim Cassette
- 230V single phase
- All GWIN™ guarantees
GWIN 9,000 BTU 230V Emperor and Multi-Zone Slim Cassette The GWIN 9,000 BTU 230V Emperor and Multi-Zone Slim Cassette is a compact indoor cassette unit designed for reliable ductless comfort in a strea...
GWIN 9,000 BTU 230V Emperor and Multi-Zone Slim Cassette
The GWIN 9,000 BTU 230V Emperor and Multi-Zone Slim Cassette is a compact indoor cassette unit designed for reliable ductless comfort in a streamlined ceiling-mounted form factor. With a nominal cooling capacity of 9,000 BTU/h and a nominal heating capacity of 9,000 BTU/h, this unit is built for use in compatible GWIN Emperor and multi-zone system applications.
This slim cassette uses R32 refrigerant and delivers an airflow range of 200 to 324 CFM with sound pressure levels from 31 to 37 dB(A). It also offers dehumidification performance of 1.69 pt/hr, helping maintain a more comfortable indoor environment while keeping operation compact and efficient.
Comfort & Control
Remote control functions for this indoor unit provide convenient day-to-day operation and flexible comfort adjustment.
- Auto Mode
- Auto Fan
- Horizontal Auto Swing
- Vertical Auto Swing
- Clock
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- Fan Speed Control (7 Speeds)
- Privacy Lock
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode
- Power Failure Mode
Key Features
- 9,000 BTU/h nominal cooling capacity
- 9,000 BTU/h nominal heating capacity
- R32 refrigerant system compatibility
- 208-230V / 1Ph / 60Hz power supply
- Airflow range of 200 - 324 CFM
- Sound pressure level of 31 - 37 dB(A)
Installation & Compatibility
This indoor slim cassette is intended for use with a compatible GWIN outdoor unit. It uses flared refrigerant line connections and is powered by the outdoor unit.
Technical Specifications
| Model Number | EMPR09HP230V1R32ACS |
| Cooling Capacity | 9,000 BTU/h |
| Heating Capacity | 9,000 BTU/h |
| Refrigerant Type | R32 |
| Power Supply | 208-230V / 1Ph / 60Hz (Powered by the Outdoor Unit) |
| Line Set Size (Liquid - Gas) - Flared Connections | 1/4" - 3/8" |
| Dehumidification | 1.69 pt/hr |
| Air Flow (Min-Max) | 200 - 324 CFM |
| Sound Pressure Level (Min - Max) | 31 - 37 dB(A) |
| External Dimensions (L x D x H) | 38-55/64 x 15-5/32 x 7-1/64 in. |
| Package Dimensions (L x W x H) | 51-29/64 x 19-23/32 x 12-13/64 in. |
| Net Weight | 41.9 lbs. |
| Gross Weight | 57.3 lbs. |
| Required Cassette Grille | GREETD01 |
| Grille Dimensions (L x D x H) | 47-1/4 x 18-7/64 x 2-11/64 in. |
| Grille Package Dimensions (L x W x H) | 49-13/16 x 21-1/8 x 4-25/32 in. |
| Grille Weight (Net / Gross) | 9.26 / 13.23 lbs. |
GWIN 12,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler
- 230V single phase
- All GWIN™ guarantees
GWIN 12,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler The GWIN 12,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit desi...
GWIN 12,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler
The GWIN 12,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit designed to deliver targeted comfort with quiet operation and modern control features. Ideal for bedrooms, offices, and medium-sized living spaces, this wall-mounted air handler provides precise temperature control while maintaining energy efficiency.
Built with advanced inverter technology and optimized airflow design, this unit ensures consistent comfort while minimizing energy consumption. Its compact design allows for flexible installation without compromising performance.
Comfort & Control
This indoor unit includes an intuitive remote control system, allowing users to easily adjust temperature, fan speed, and operating modes for personalized comfort.
- Wireless remote control included
- Auto Mode
- Auto Fan
- Horizontal Auto Swing
- Vertical Auto Swing
- Clock on Remote Controller
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- I Feel Function
- Lock on Remote Controller
- Quiet Mode
- Room Temperature Display
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode (46°F)
Key Features
- 12,000 BTU cooling and heating capacity
- 208-230V power supply
- Wall-mounted compact design
- Inverter-driven performance
- Whisper-quiet operation
- Energy-efficient operation
Installation & Compatibility
This indoor air handler is designed to pair seamlessly with the GWIN King Single Zone condenser for a complete ductless system solution.
Technical Specifications
| Model Number | KING12HP230V1R32AH |
| Cooling Capacity | 12,000 BTU/h |
| Heating Capacity | 12,000 BTU/h |
| Power Supply | 208-230V / 1Ph / 60Hz (Powered by the Outdoor Unit) |
| Electrical Connection | Indoor to Outdoor Communication Wiring Required |
| Line Set Size (Liquid - Gas) | 1/4" - 3/8" |
| Pipe Length (Min - Max) | 10 - 66 ft. |
| Max Pipe Elevation | 40 ft. |
| Dehumidification | 2.96 pt/hr |
| Air Flow (Min-Max) | 182 - 424 CFM |
| Sound Pressure Level | 27 - 47 dB(A) |
| External Dimensions (W x H x D) | 32-7/8 x 10-53/64 x 7-7/8 in. |
| Package Dimension (W x H x D) | 35-15/64 x 13-37/64 x 10-43/64 in. |
| Net Weight | 19.8 lbs. |
| Gross Weight | 24.3 lbs. |
| Voltage Range (Min - Max) | 187 - 253 VAC |
| Rated Current - Cooling | 7.02 A |
| Rated Current - Heating | 7.47 A |
| MOCP | 15 A |
| MCA | 12 A |
| Main Power Wire Size | Per Local Code |
| Interconnecting Wire Size | 14 / 4 AWG |
GWIN 12,000 BTU 230V Emperor Single Ductless Wall Mount Air Handler
- 230V single phase
- All GWIN™ guarantees
GWIN 12,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler The GWIN 12,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor uni...
GWIN 12,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler
The GWIN 12,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit designed to deliver targeted comfort with quiet operation and modern control features. Ideal for bedrooms, offices, and medium-sized living spaces, this wall-mounted air handler provides precise temperature control while maintaining energy efficiency.
Built with advanced inverter technology and optimized airflow design, this unit ensures consistent comfort while minimizing energy consumption. Its compact design allows for flexible installation without compromising performance.
Comfort & Control
This indoor unit includes an intuitive remote control system, allowing users to easily adjust temperature, fan speed, and operating modes for personalized comfort.
- Wireless remote control included
- Auto Mode
- Auto Fan
- Horizontal Auto Swing
- Vertical Auto Swing
- Clock on Remote Controller
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- I Feel Function
- Lock on Remote Controller
- Quiet Mode
- Room Temperature Display
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode (46°F)
Key Features
- 12,000 BTU cooling and heating capacity
- 208-230V power supply
- Wall-mounted compact design
- Inverter-driven performance
- Whisper-quiet operation
- Energy-efficient operation
Installation & Compatibility
This indoor air handler is designed to pair seamlessly with the GWIN King Single Zone condenser for a complete ductless system solution.
Technical Specifications
| Model Number | EMPR12HP230V1R32AH |
| Cooling Capacity | 12,000 BTU/h |
| Heating Capacity | 12,000 BTU/h |
| Power Supply | 208-230V / 1Ph / 60Hz (Powered by the Outdoor Unit) |
| Electrical Connection | Indoor to Outdoor Communication Wiring Required |
| Line Set Size (Liquid - Gas) | 1/4" - 3/8" |
| Pipe Length (Min - Max) | 10 - 66 ft. |
| Max Pipe Elevation | 40 ft. |
| Dehumidification | 2.96 pt/hr |
| Air Flow (Min-Max) | 182 - 424 CFM |
| Sound Pressure Level | 27 - 47 dB(A) |
| External Dimensions (W x H x D) | 32-7/8 x 10-53/64 x 7-7/8 in. |
| Package Dimension (W x H x D) | 35-15/64 x 13-37/64 x 10-43/64 in. |
| Net Weight | 19.8 lbs. |
| Gross Weight | 24.3 lbs. |
| Voltage Range (Min - Max) | 187 - 253 VAC |
| Rated Current - Cooling | 7.02 A |
| Rated Current - Heating | 7.47 A |
| MOCP | 15 A |
| MCA | 12 A |
| Main Power Wire Size | Per Local Code |
| Interconnecting Wire Size | 14 / 4 AWG |
GWIN 12,000 BTU 230V Emperor and Multi-Zone Slim Cassette
- 230V single phase
- All GWIN™ guarantees
GWIN 12,000 BTU 230V Emperor and Multi-Zone Slim Cassette The GWIN 12,000 BTU 230V Emperor and Multi-Zone Slim Cassette is a compact indoor cassette unit built for dependable comfort in compatible duct...
GWIN 12,000 BTU 230V Emperor and Multi-Zone Slim Cassette
The GWIN 12,000 BTU 230V Emperor and Multi-Zone Slim Cassette is a compact indoor cassette unit built for dependable comfort in compatible ductless applications. With a nominal cooling capacity of 12,000 BTU/h and a nominal heating capacity of 12,000 BTU/h, it is well suited for GWIN Emperor and multi-zone system pairings.
This slim cassette uses R32 refrigerant and provides an airflow range of 230 to 353 CFM with sound pressure levels from 34 to 41 dB(A). It also delivers 2.96 pt/hr of dehumidification performance for improved indoor comfort in a low-profile ceiling cassette design.
Comfort & Control
Remote control functions for this indoor unit are designed to make comfort adjustment simple and flexible.
- Auto Mode
- Auto Fan
- Horizontal Auto Swing
- Vertical Auto Swing
- Clock
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- Fan Speed Control (7 Speeds)
- Privacy Lock
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode
- Power Failure Mode
Key Features
- 12,000 BTU/h nominal cooling capacity
- 12,000 BTU/h nominal heating capacity
- R32 refrigerant system compatibility
- 208-230V / 1Ph / 60Hz power supply
- Airflow range of 230 - 353 CFM
- Sound pressure level of 34 - 41 dB(A)
Installation & Compatibility
This indoor slim cassette is intended for use with a compatible GWIN outdoor unit. It uses flared refrigerant line connections and is powered by the outdoor unit.
Technical Specifications
| Model Number | EMPR12HP230V1R32ACS |
| Cooling Capacity | 12,000 BTU/h |
| Heating Capacity | 12,000 BTU/h |
| Refrigerant Type | R32 |
| Power Supply | 208-230V / 1Ph / 60Hz (Powered by the Outdoor Unit) |
| Line Set Size (Liquid - Gas) - Flared Connections | 1/4" - 3/8" |
| Dehumidification | 2.96 pt/hr |
| Air Flow (Min-Max) | 230 - 353 CFM |
| Sound Pressure Level (Min - Max) | 34 - 41 dB(A) |
| External Dimensions (L x D x H) | 38-55/64 x 15-5/32 x 7-1/64 in. |
| Package Dimensions (L x W x H) | 51-29/64 x 19-23/32 x 12-13/64 in. |
| Net Weight | 41.9 lbs. |
| Gross Weight | 57.3 lbs. |
| Required Cassette Grille | GREETD01 |
| Grille Dimensions (L x D x H) | 47-1/4 x 18-7/64 x 2-11/64 in. |
| Grille Package Dimensions (L x W x H) | 49-13/16 x 21-1/8 x 4-25/32 in. |
| Grille Weight (Net / Gross) | 9.26 / 13.23 lbs. |
GWIN 18,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler
- 230V single phase
- All GWIN™ guarantees
GWIN 18,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler The GWIN 18,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit desi...
GWIN 18,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler
The GWIN 18,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit designed to deliver targeted comfort with quiet operation and modern control features. Ideal for bedrooms, offices, and medium-sized living spaces, this wall-mounted air handler provides precise temperature control while maintaining energy efficiency.
Built with advanced inverter technology and optimized airflow design, this unit ensures consistent comfort while minimizing energy consumption. Its compact design allows for flexible installation without compromising performance.
Comfort & Control
This indoor unit includes an intuitive remote control system, allowing users to easily adjust temperature, fan speed, and operating modes for personalized comfort.
- Wireless remote control included
- Auto Mode
- Auto Fan
- Horizontal Auto Swing
- Vertical Auto Swing
- Clock on Remote Controller
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- I Feel Function
- Lock on Remote Controller
- Quiet Mode
- Room Temperature Display
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode (46°F)
Key Features
- 18,000 BTU cooling and heating capacity
- 208-230V power supply
- Wall-mounted compact design
- Inverter-driven performance
- Whisper-quiet operation
- Energy-efficient operation
Installation & Compatibility
This indoor air handler is designed to pair seamlessly with the GWIN King Single Zone condenser for a complete ductless system solution.
Technical Specifications
| Model Number | KING18HP230V1R32AH |
| Cooling Capacity | 18,000 BTU/h |
| Heating Capacity | 19,100 BTU/h |
| Power Supply | 208-230V / 1Ph / 60Hz (Powered by the Outdoor Unit) |
| Electrical Connection | Indoor to Outdoor Communication Wiring Required |
| Line Set Size (Liquid - Gas) | 1/4" - 1/2" |
| Pipe Length (Min - Max) | 10 - 82 ft. |
| Max Pipe Elevation | 33 ft. |
| Dehumidification | 3.80 pt/hr |
| Air Flow (Min-Max) | 282 - 618 CFM |
| Sound Pressure Level | 34 - 53 dB(A) |
| External Dimensions (W x H x D) | 37-1/8 x 13-7/64 x 9-11/16 in. |
| Package Dimension (W x H x D) | 39-13/32 x 15-15/16 x 12-43/64 in. |
| Net Weight | 28.7 lbs. |
| Gross Weight | 34.2 lbs. |
| Voltage Range (Min - Max) | 187 - 253 VAC |
| Rated Current - Cooling | 9.5 A |
| Rated Current - Heating | 9.5 A |
| MOCP | 15 A |
| MCA | 13 A |
| Main Power Wire Size | Per Local Code |
| Interconnecting Wire Size | 14 / 4 AWG |
GWIN 18,000 BTU 230V Emperor Single Ductless Wall Mount Air Handler
- 230V single phase
- All GWIN™ guarantees
GWIN 18,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler The GWIN 18,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor uni...
GWIN 18,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler
The GWIN 18,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit designed to deliver targeted comfort with quiet operation and modern control features. Ideal for bedrooms, offices, and medium-sized living spaces, this wall-mounted air handler provides precise temperature control while maintaining energy efficiency.
Built with advanced inverter technology and optimized airflow design, this unit ensures consistent comfort while minimizing energy consumption. Its compact design allows for flexible installation without compromising performance.
Comfort & Control
This indoor unit includes an intuitive remote control system, allowing users to easily adjust temperature, fan speed, and operating modes for personalized comfort.
- Wireless remote control included
- Auto Mode
- Auto Fan
- Horizontal Auto Swing
- Vertical Auto Swing
- Clock on Remote Controller
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- I Feel Function
- Lock on Remote Controller
- Quiet Mode
- Room Temperature Display
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode (46°F)
Key Features
- 18,000 BTU cooling and heating capacity
- 208-230V power supply
- Wall-mounted compact design
- Inverter-driven performance
- Whisper-quiet operation
- Energy-efficient operation
Installation & Compatibility
This indoor air handler is designed to pair seamlessly with the GWIN Emperor Single Zone condenser for a complete ductless system solution.
Technical Specifications
| Model Number | EMPR18HP230V1R32AH |
| Cooling Capacity | 18,000 BTU/h |
| Heating Capacity | 19,100 BTU/h |
| Power Supply | 208-230V / 1Ph / 60Hz (Powered by the Outdoor Unit) |
| Electrical Connection | Indoor to Outdoor Communication Wiring Required |
| Line Set Size (Liquid - Gas) | 1/4" - 1/2" |
| Pipe Length (Min - Max) | 10 - 82 ft. |
| Max Pipe Elevation | 33 ft. |
| Dehumidification | 3.80 pt/hr |
| Air Flow (Min-Max) | 282 - 618 CFM |
| Sound Pressure Level | 34 - 53 dB(A) |
| External Dimensions (W x H x D) | 37-1/8 x 13-7/64 x 9-11/16 in. |
| Package Dimension (W x H x D) | 39-13/32 x 15-15/16 x 12-43/64 in. |
| Net Weight | 28.7 lbs. |
| Gross Weight | 34.2 lbs. |
| Voltage Range (Min - Max) | 187 - 253 VAC |
| Rated Current - Cooling | 9.5 A |
| Rated Current - Heating | 9.5 A |
| MOCP | 15 A |
| MCA | 13 A |
| Main Power Wire Size | Per Local Code |
| Interconnecting Wire Size | 14 / 4 AWG |
GWIN 20,000 BTU 230V Emperor and Multi-Zone Slim Cassette
- 230V single phase
- All GWIN™ guarantees
GWIN 20,000 BTU 230V Emperor and Multi-Zone Slim Cassette The GWIN 20,000 BTU 230V Emperor and Multi-Zone Slim Cassette is a larger-capacity indoor cassette unit designed for dependable comfort in comp...
GWIN 20,000 BTU 230V Emperor and Multi-Zone Slim Cassette
The GWIN 20,000 BTU 230V Emperor and Multi-Zone Slim Cassette is a larger-capacity indoor cassette unit designed for dependable comfort in compatible ductless applications. With a nominal cooling capacity of 20,000 BTU/h and a nominal heating capacity of 20,000 BTU/h, it is intended for use in GWIN Emperor and multi-zone system configurations.
This slim cassette uses R32 refrigerant and delivers an airflow range of 294 to 441 CFM with sound pressure levels from 36 to 46 dB(A). It also provides 4.23 pt/hr of dehumidification performance to support comfort in higher-capacity applications while maintaining a compact cassette profile.
Comfort & Control
Remote control functions for this indoor unit make it easy to tailor system operation to the space and the season.
- Auto Mode
- Auto Fan
- Horizontal Auto Swing
- Vertical Auto Swing
- Clock
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- Fan Speed Control (7 Speeds)
- Privacy Lock
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode
- Power Failure Mode
Key Features
- 20,000 BTU/h nominal cooling capacity
- 20,000 BTU/h nominal heating capacity
- R32 refrigerant system compatibility
- 208-230V / 1Ph / 60Hz power supply
- Airflow range of 294 - 441 CFM
- Sound pressure level of 36 - 46 dB(A)
Installation & Compatibility
This indoor slim cassette is intended for use with a compatible GWIN outdoor unit. It uses flared refrigerant line connections and is powered by the outdoor unit.
Technical Specifications
| Model Number | EMPR18HP230V1R32ACS |
| Cooling Capacity | 20,000 BTU/h |
| Heating Capacity | 20,000 BTU/h |
| Refrigerant Type | R32 |
| Power Supply | 208-230V / 1Ph / 60Hz (Powered by the Outdoor Unit) |
| Line Set Size (Liquid - Gas) - Flared Connections | 1/4" - 1/2" |
| Dehumidification | 4.23 pt/hr |
| Air Flow (Min-Max) | 294 - 441 CFM |
| Sound Pressure Level (Min - Max) | 36 - 46 dB(A) |
| External Dimensions (L x D x H) | 38-55/64 x 15-5/32 x 7-1/64 in. |
| Package Dimensions (L x W x H) | 51-29/64 x 19-23/32 x 12-13/64 in. |
| Net Weight | 44.1 lbs. |
| Gross Weight | 59.5 lbs. |
| Required Cassette Grille | GREETD01 |
| Grille Dimensions (L x D x H) | 47-1/4 x 18-7/64 x 2-11/64 in. |
| Grille Package Dimensions (L x W x H) | 49-13/16 x 21-1/8 x 4-25/32 in. |
| Grille Weight (Net / Gross) | 9.26 / 13.23 lbs. |
GWIN 24,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler
- 230V single phase
- All GWIN™ guarantees
GWIN 24,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler The GWIN 24,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit desi...
GWIN 24,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler
The GWIN 24,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit designed to deliver targeted comfort with quiet operation and modern control features. Ideal for bedrooms, offices, and medium-sized living spaces, this wall-mounted air handler provides precise temperature control while maintaining energy efficiency.
Built with advanced inverter technology and optimized airflow design, this unit ensures consistent comfort while minimizing energy consumption. Its compact design allows for flexible installation without compromising performance.
Comfort & Control
This indoor unit includes an intuitive remote control system, allowing users to easily adjust temperature, fan speed, and operating modes for personalized comfort.
- Wireless remote control included
- Auto Mode
- Auto Fan
- Horizontal Auto Swing
- Vertical Auto Swing
- Clock on Remote Controller
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- I Feel Function
- Lock on Remote Controller
- Quiet Mode
- Room Temperature Display
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode (46°F)
Key Features
- 24,000 BTU cooling and heating capacity
- 208-230V power supply
- Wall-mounted compact design
- Inverter-driven performance
- Whisper-quiet operation
- Energy-efficient operation
Installation & Compatibility
This indoor air handler is designed to pair seamlessly with the GWIN King Single Zone condenser for a complete ductless system solution.
Technical Specifications
| Model Number | KING24HP230V1R32AH |
| Cooling Capacity | 24,000 BTU/h |
| Heating Capacity | 24,000 BTU/h |
| Power Supply | 208-230V / 1Ph / 60Hz |
| Electrical Connection | Indoor to Outdoor Communication Wiring Required |
| Line Set Size (Liquid - Gas) | 1/4" - 1/2" |
| Pipe Length (Min - Max) | 10 - 131 ft. |
| Max Pipe Elevation | 82 ft. |
| Dehumidification | 5.28 pt/hr |
| Air Flow (Min-Max) | 412 - 677 CFM |
| Sound Pressure Level | 36 - 51 dB(A) |
| External Dimensions (W x H x D) | 42-7/16 x 13-7/64 x 9-11/16 in. |
| Package Dimension (W x H x D) | 44-39/64 x 16-19/64 x 13-7/64 in. |
| Net Weight | 33.1 lbs. |
| Gross Weight | 39.7 lbs. |
GWIN 24,000 BTU 230V Emperor Single Ductless Wall Mount Air Handler
- 230V single phase
- All GWIN™ guarantees
GWIN 24,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler The GWIN 24,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor uni...
GWIN 24,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler
The GWIN 24,000 BTU 230V Emperor Single and Multi-Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit designed to deliver targeted comfort with quiet operation and modern control features. Ideal for bedrooms, offices, and medium-sized living spaces, this wall-mounted air handler provides precise temperature control while maintaining energy efficiency.
Built with advanced inverter technology and optimized airflow design, this unit ensures consistent comfort while minimizing energy consumption. Its compact design allows for flexible installation without compromising performance.
Comfort & Control
This indoor unit includes an intuitive remote control system, allowing users to easily adjust temperature, fan speed, and operating modes for personalized comfort.
- Wireless remote control included
- Auto Mode
- Auto Fan
- Horizontal Auto Swing
- Vertical Auto Swing
- Clock on Remote Controller
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- I Feel Function
- Lock on Remote Controller
- Quiet Mode
- Room Temperature Display
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode (46°F)
Key Features
- 24,000 BTU cooling and heating capacity
- 208-230V power supply
- Wall-mounted compact design
- Inverter-driven performance
- Whisper-quiet operation
- Energy-efficient operation
Installation & Compatibility
This indoor air handler is designed to pair seamlessly with the GWIN Emperor Single Zone condenser for a complete ductless system solution.
Technical Specifications
| Model Number | EMPR24HP230V1R32AH |
| Cooling Capacity | 24,000 BTU/h |
| Heating Capacity | 24,000 BTU/h |
| Power Supply | 208-230V / 1Ph / 60Hz (Powered by the Outdoor Unit) |
| Electrical Connection | Indoor to Outdoor Communication Wiring Required |
| Line Set Size (Liquid - Gas) | 1/4" - 1/2" |
| Pipe Length (Min - Max) | 10 - 131 ft. |
| Max Pipe Elevation | 82 ft. |
| Dehumidification | 5.28 pt/hr |
| Air Flow (Min-Max) | 412 - 677 CFM |
| Sound Pressure Level | 36 - 51 dB(A) |
| External Dimensions (W x H x D) | 42-7/16 x 13-7/64 x 9-11/16 in. |
| Package Dimension (W x H x D) | 44-39/64 x 16-19/64 x 13-7/64 in. |
| Net Weight | 33.1 lbs. |
| Gross Weight | 39.7 lbs. |
| Voltage Range (Min - Max) | 187 - 253 VAC |
| Rated Current - Cooling | 11 A |
| Rated Current - Heating | 12 A |
| MOCP | 20 A |
| MCA | 15 A |
| Main Power Wire Size | Per Local Code |
| Interconnecting Wire Size | 14 / 4 AWG |
GWIN 30,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler
- 230V single phase
- All GWIN™ guarantees
GWIN 30,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler The GWIN 30,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit desi...
GWIN 30,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler
The GWIN 30,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit designed to deliver targeted comfort with quiet operation and modern control features. Ideal for bedrooms, offices, and medium-sized living spaces, this wall-mounted air handler provides precise temperature control while maintaining energy efficiency.
Built with advanced inverter technology and optimized airflow design, this unit ensures consistent comfort while minimizing energy consumption. Its compact design allows for flexible installation without compromising performance.
Comfort & Control
This indoor unit includes an intuitive remote control system, allowing users to easily adjust temperature, fan speed, and operating modes for personalized comfort.
- Wireless remote control included
- Auto Mode
- Auto Fan
- Horizontal Auto Swing
- Vertical Auto Swing
- Clock on Remote Controller
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- I Feel Function
- Lock on Remote Controller
- Quiet Mode
- Room Temperature Display
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode (46°F)
Key Features
- 30,000 BTU cooling and heating capacity
- 208-230V power supply
- Wall-mounted compact design
- Inverter-driven performance
- Whisper-quiet operation
- Energy-efficient operation
Installation & Compatibility
This indoor air handler is designed to pair seamlessly with the GWIN King Single Zone condenser for a complete ductless system solution.
Technical Specifications
| Model Number | KING30HP230V1R32AH |
| Cooling Capacity | 30,000 BTU/h |
| Heating Capacity | 30,000 BTU/h |
| Power Supply | 208-230V / 1Ph / 60Hz |
| Electrical Connection | Indoor to Outdoor Communication Wiring Required |
| Line Set Size (Liquid - Gas) | 1/4" - 5/8" |
| Pipe Length (Min - Max) | 10 - 131 ft. |
| Max Pipe Elevation | 82 ft. |
| Dehumidification | 7.40 pt/hr |
| Air Flow (Min-Max) | 441 - 794 CFM |
| Sound Pressure Level | 36 - 52 dB(A) |
| External Dimensions (W x H x D) | 42-7/16 x 13-7/64 x 9-11/16 in. |
| Package Dimension (W x H x D) | 44-39/64 x 16-19/64 x 13-7/64 in. |
| Net Weight | 34.2 lbs. |
| Gross Weight | 40.8 lbs. |
GWIN 36,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler
- 230V single phase
- All GWIN™ guarantees
GWIN 36,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler The GWIN 36,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit desi...
GWIN 36,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler
The GWIN 36,000 BTU 230V King Single and Multi Zone Ductless Wall Mount Air Handler is a sleek and efficient indoor unit designed to deliver targeted comfort with quiet operation and modern control features. Ideal for bedrooms, offices, and larger living spaces, this wall-mounted air handler provides precise temperature control while maintaining energy efficiency.
Built with advanced inverter technology and optimized airflow design, this unit ensures consistent comfort while minimizing energy consumption. Its compact design allows for flexible installation without compromising performance.
Comfort & Control
This indoor unit includes an intuitive remote control system, allowing users to easily adjust temperature, fan speed, and operating modes for personalized comfort.
- Wireless remote control included
- Auto Mode
- Auto Fan
- Manual Horizontal Swing
- Vertical Auto Swing
- Clock on Remote Controller
- Dry Mode
- Dry Anti-Mildew (X-Fan) Mode
- Energy Saving Mode
- I Feel Function
- Lock on Remote Controller
- Quiet Mode
- Room Temperature Display
- Sleep Mode
- Timer Mode
- Turbo Mode
- Display On/Off Control
- Freeze Guard Mode (46°F)
Key Features
- 36,000 BTU cooling and heating capacity
- 208-230V power supply
- Wall-mounted compact design
- Inverter-driven performance
- Whisper-quiet operation
- Energy-efficient operation
Installation & Compatibility
This indoor air handler is designed to pair seamlessly with the GWIN King Single Zone condenser for a complete ductless system solution.
Technical Specifications
| Model Number | KING36HP230V1R32AH |
| Cooling Capacity | 36,000 BTU/h |
| Heating Capacity | 36,000 BTU/h |
| Power Supply | 208-230V / 1Ph / 60Hz (Powered by the Outdoor Unit) |
| Electrical Connection | Indoor to Outdoor Communication Wiring Required |
| Voltage Range (Min - Max) | 187 - 253 VAC |
| Rated Current - Cooling | 20 A |
| Rated Current - Heating | 20 A |
| MOCP | 35 A |
| MCA | 24 A |
| Main Power Wire Size | Per Local Code |
| Interconnecting Wire Size | 14 / 4 AWG |
| Line Set Size (Liquid - Gas) | 1/4" - 5/8" |
| Pipe Length (Min - Max) | 10 - 131 ft. |
| Max Pipe Elevation | 82 ft. |
| Dehumidification | 7.40 pt/hr |
| Air Flow (Min-Max) | 441 - 794 CFM |
| Sound Pressure Level | 36 - 52 dB(A) |
| External Dimensions (W x H x D) | 42-7/16 x 13-7/64 x 9-11/16 in. |
| Package Dimension (W x H x D) | 44-39/64 x 16-19/64 x 13-7/64 in. |
| Net Weight | 34.2 lbs. |
| Gross Weight | 40.8 lbs. |
Condenser Ground Stand Brackets
Specifications and dimensions: Length 35" x Width 18" x Height 11" Loading capacity 264 lbs
Condenser Pad
This condenser pad will fit all of the GWIN Condensers available. Why purchase an Condenser Pad? 1. Protects the unit from pest, insects and critters that may cause damage to the condenser. 2. Reduce vibration from t...
This condenser pad will fit all of the GWIN Condensers available.
Why purchase an Condenser Pad?
1. Protects the unit from pest, insects and critters that may cause damage to the condenser.
2. Reduce vibration from the AC against this pad so it does not hit against the ground. If a condenser is not placed on a support system like a pad, you risk damage being done each time the condenser vibrates against the ground.
Pros
- Unaffected by UV or weather
- Uniform rubbing transfers load evenly
- Lightweight, yet incredibly rugged
Material Type: Polypropylene
Condensers Wall Mounting Bracket 18k-36k
Wall mounting brackets for condensers. Can hold up to 3 tons (36k) condensers. Specifications and dimensions: 31x16x20 in. 300 lbs loading capacity Suitable for 9,000-36,000 BTU condensers Equipped with security...
Wall mounting brackets for condensers. Can hold up to 3 tons (36k) condensers.
Specifications and dimensions:
- 31x16x20 in.
- 300 lbs loading capacity
- Suitable for 9,000-36,000 BTU condensers
- Equipped with security clip
- Preassembled set
Disconnect Switch and Electrical Whip with #10 AWG
No description available.
GWIN Line Covers
GWIN 4" x 14 ft. Mini-Split Line Set Cover Kit – Paintable, Weather-Resistant HVAC Protection Give your mini-split installation a clean, professional finish with the GWIN Mini-Split Line Set Cover Kit. Des...
GWIN 4" x 14 ft. Mini-Split Line Set Cover Kit – Paintable, Weather-Resistant HVAC Protection
Give your mini-split installation a clean, professional finish with the GWIN Mini-Split Line Set Cover Kit. Designed to conceal and protect refrigerant tubing, electrical wiring, and drain lines, this durable cover system enhances curb appeal while helping extend the life of your HVAC components. Ideal for residential or light commercial installations, both indoors and outdoors.
Key Features & Benefits
- Complete Installation Kit: Includes straight line-set channels, couplers, wall cover, end cap, and an adjustable elbow for a streamlined, finished look.
- Generous 4" x 14 ft. Coverage: Fits most standard mini-split line sets, electrical cables, and drain hoses with ample interior space for easy routing.
- Durable & Weather-Resistant Construction: Built from high-quality, UV-resistant material to help protect HVAC lines from sun exposure, moisture, debris, and environmental wear.
- Paintable for a Seamless Look: Clean white finish can be painted to match siding, brick, stucco, or interior walls for a custom appearance.
- Easy, Modular Installation: Snap-together design supports quick installation with minimal tools—great for HVAC professionals and DIY homeowners.
Why Choose GWIN?
GWIN accessories are designed to deliver professional-grade performance with clean aesthetics. This line set cover kit not only protects vital HVAC components, but also elevates the overall appearance of your installation so it blends seamlessly into any space.
Product Specifications
- Brand: GWIN
- Application: Mini-split systems, heat pumps, air conditioners
- Coverage Length: 14 ft
- Width: 4 inches
- Color: White (paintable)
- Material: Weather- and UV-resistant PVC
- Indoor / Outdoor Use: Yes
- Installation Type: Surface-mounted, modular snap-fit
Included in This Kit
- Straight line-set cover sections
- Couplers
- Adjustable elbow (90°–120°)
- Wall penetration cover
- End cap
Note: Paint before installation for best results. Verify measurements and routing requirements prior to mounting.
Disconnect Switch and Electrical Whip with #8 AWG
No description available.
PVC Line Covers
Line set covers Specifications and dimensions: 13 ft length 3 inches width 2 head wall covers Extra white covers Cold resistance: -40°F Heat resistance: 140°F Lifespan exceeding 10 years
